Geberit 116.025.SN.1 Mambo Touch or No-Touch Urinal Flush Plate, Stainless Steel

Product Description Elegant actuator flush panels are distinguished with attractive, unmistakable design. Geberit actuators give each bathroom special charm, and incorporate water saving possibilities with dual- or single-flush functionality. This visible element, available in multiple styles, finishes and materials, provides the finishing touch to your design. Power failure protection (ensure valve closes in the event of power failure during open cycle) Tool-free maintenance, with access to power supply and flush valve behind the actuator plate Detection distance: 4 - 20 in (10 - 50 cm) Dynamic flushing time reduction during periods of high traffic to reduce water consumption Automatic hygiene flush: 24 h after last flush cycle User detection time: 7 s Operating voltage: 110-240V AC, 50-60Hz / Power input <0.5 W For low consumption urinal flushing volumes to 0.5 GPF (2 LPF) Flow rate at 15 psi (1 bar): 3.8 / 4.7 gpm without flow limiter (0.24 / 0.3 l/s) Flushing time: 3 - 15 s (default time 4 s); can be manually adjusted Humidity <100% (relative) Operating pressure range: 14 - 116 psi (1 - 8 bar) Max. fluid temp: 86 DegreeF (30 DegreeC) Includes cover plate with replaceable infrared window and securing bar, infrared control pre-mounted on frame, solenoid valve, fastening material, CLASS 2 power supply Note: Not for use with 111.630, 111.650, 111.679, or 111.685 urinal elements From the Manufacturer Elegant actuator flush panels are distinguished with attractive, unmistakable design. Geberit actuators give each bathroom special charm, and incorporate water saving possibilities with dual- or single-flush functionality. This visible element, available in multiple styles, finishes and materials, provides the finishing touch to your design. Power failure protection (ensure valve closes in the event of power failure during open cycle) Tool-free maintenance, with access to power supply and flush valve behind the actuator plate Detection distance: 4 - 20 in (10 - 50 cm) Dynamic flushing time reduction during periods of high traffic to reduce water consumption Automatic hygiene flush: 24 h after last flush cycle User detection time: 7 s Operating voltage: 110-240V AC, 50-60Hz / Power input <0.5 W For low consumption urinal flushing volumes to 0.5 GPF (2 LPF) Flow rate at 15 psi (1 bar): 3.8 / 4.7 gpm without flow limiter (0.24 / 0.3 l/s) Flushing time: 3 - 15 s (default time 4 s); can be manually adjusted Humidity <100% (relative) Operating pressure range: 14 - 116 psi (1 - 8 bar) Max. fluid temp: 86 DegreeF (30 DegreeC) Includes cover plate with replaceable infrared window and securing bar, infrared control pre-mounted on frame, solenoid valve, fastening material, CLASS 2 power supply Note: Not for use with 111.630, 111.650, 111.679, or 111.685 urinal elements

• AC powered, infrared-controlled flushing for hands-free operation in hygienic or ADA compliant applications
• For concealed installation in new construction, or retrofit to pre-installed Geberit urinal element 111.625 with front actuation
• Power failure protection (ensure valve closes in the event of power failure during open cycle)
• Detection distance: 4 - 20 in (10 - 50 cm)
• Not for use with 111.630, 111.650, 111.679, or 111.685 urinal elements
